Description
Technical data
| Parameter | Specification |
|---|---|
| Leaf material | Glass |
| Leaf weight (max.) | 80 kg |
| Leaf weight (max.) with draw-in damper | 40 kg |
| Number of leaves | 1-leaf, 2-leaf |
| Leaf width (min.) | 500 mm |
| Leaf width (max.) | 1640 mm |
| Test cycles | 50,000 |
| Corrosion protection class | 1 |
| Pane thickness | 8 – 10 mm |
| Type of installation | Wall, Ceiling |
| Accessibility (DIN 18040) | Yes (Access for all) |
