Description
Technical data
| Parameter | Specification |
|---|---|
| Closing force in accordance with EN 1154 | EN 2 – 4 |
| Barrier-free in accordance with DIN 18040 up to leaf width (max.) | 1100 mm |
| Leaf width (max.) | 1100 mm |
| Type of installation | Transom installation opposite hinge side |
| Suitability for fire protection doors | Yes |
| Closing force adjustable | Yes, stepless |
| Latching action adjustable | Yes, via valve |
| Back check integrated | Yes, hydraulically adjustable |
| Position of closing force adjustment | At the side |
| Hold-open function | Optional |
